Light, versatile, and easy to use, Trilogy makes invasive and noninvasive home ventilation less complicated with a simplified user interface and Respironics proven BiPAP technology for greater versatility. Its lightweight design and internal and detachable batteries make portability easier for patients on the go. Whether at home or in alternative care sites, the Trilogy 100 portable volume and pressure support ventilator with BiPAP technology is made for adult and pediatric use.
Respironics Trilogy 100 Ventilator, #1054260
Environmental
Temperature
5°C – 40°C
Relative humidity
15% – 95%
Atmospheric pressure
110 kPa to 60 kPa
Physical
Weight
11 lbs, 5 kgs
Size
6.6"L x 11.2"W x 9.3"H (16.68 cm L x 28.45 cm W x 23.52 cm H)
Controls
Circuit types
Active with PAP, passive
Ventilation types
Volume control, pressure control, bilevel
Volume modes
AC, SIMV (w/PS), CV
Pressure modes
CPAP, S, S/T, T, PC-SIMV (w/PS)
IPAP
4 – 50 cm H20
EPAP
0 – 25 cm H20 for active circuits 4 – 25 cm H20 for passive circuits
CPAP
4 – 20 cm H20 for passive circuits
PEEP
0 – 25 cm H20 for active circuits 4 – 25 cm H20 for passive circuits
Pressure support differential
0 – 30 cm H20
Measured patient parameters
Tidal volume
50 – 2000 ml
Breath rate
0 – 60 for AC mode 1 – 60 for all other modes
Inspiratory time
0.3 – 5.0 secs
Rise time
1 – 6
Ramp start pressure
0 – 25 cm H20 for active circuits 4 – 25 cm H20 for passive circuits 4 – 19 cm H20 in CPAP mode
